April 28, 2023


	Bidirect or even multi compartment runs can be performed easily with EDC’s flatbed professional: 104 samples on one gel! Especially for typing wheat and barley varieties EDC developed these “SoftGels EQ-type” Ready-To-Use gels. Special optimized pH-gradient for this application. For maice and other not water-soluble protein patterns - see DryGels IEF bidirect




		bidirectional IEF on flatbed professional




		104 samples (wheat varieties)


	IEFGels bidirect (SoftGels* EQ-type, Ready-To-Use, on backing films)

name	order	gels, dimensions	slots	support	price (EUR)
IEFGel cereal 104S SoftGel EQ-type **	edc-1022	4 gels 250 x 110 x 0,5 mm	104 slots à 5 µl (2 x 52 slots, bidirect)	PET	307
IEFGel 6-11 bidirect 80S large	edc-1003	4 gels 250 x 180 x 0,5 mm	2 x 40 slots à 10 ul (bidirect)	PET	451


	* soft and hydrophylic matrix * multipipette-compatible
